ADI expands GaN PA portfolio

                      Broadband amplifier modules target applications operating between 2GHz and 6GHz

Analog Devices has announced a pair of high-performance GaN power amplifier (PA) modules which are claimed to offer one of the highest power-density levels in their class, minimising size and weight.

The HMC7885 and HMC7748 broadband modules target applications operating between 2 GHz and 6 GHz, including test and measurement, communications, Traveling Wave Tube (TWT) replacement, military/aerospace surveillance and countermeasures, and radar. The fully integrated, all solid-state devices expand ADI’s existing line of GaN-based PAs, and feature ease of use to accelerate prototyping and system design.

The HMC7885 is a 32W, hermetically sealed, hybrid amplifier housed in a hermetic flange-mount package for high-reliability applications. This hybrid amplifier typically provides 21dB of small-signal gain and 45dBm of saturated RF-output power.

The device draws 2.2A of quiescent current from a 28V dc supply. Both RF input and output are DC blocked and matched to 50 ohms for ease of use. An evaluation board is available with layout and bill of materials to facilitate design-in and user application.

The HMC7748 is a fully integrated multistage power amplifier module which delivers 25W of saturated output power, accepts inputs up to ±8 dBm maximum, and provides small-signal gain of 60 dB. It includes bias sequencing and regulation, and is also internally matched to 50 ohms.

This PA draws 0.7A from a 12V supply and up to 4A from a 28V supply. It includes an enable pin to provide shutdown capability so the amplifier can be turned on and off without cycling the power supplies.

These GaN power amplifiers provide significant advances in performance and packaging, for broadband, medium-power applications up to 6 GHz  –  all of which make for a critical combination with today’s size, weight, and power (SWaP).
