Raytheon GaN Radar Surpasses 1000 Operational Hours

Company ready to ‘take the next step and get this radar into the hands of our customers’

Raytheon has announced that its GaN-powered Active Electronically Scanned Array (AESA) proposed upgrade to the Patriot Air and Missile Defense has surpassed more than 1,000 hours of operation in just over a year –  half the time of a typical testing program.

“We achieved this milestone so quickly because of our successful experience developing and maturing GaN for programs like the US Navy’s Air and Missile Defense Radar,” said Doug Burgess, director of AESA programs at Raytheon’s Integrated Defense Systems business. “We’re ready to take the next step and get this radar into the hands of our customers.”

During the course of the 1,000 hours, Raytheon’s GaN-based AESA prototype radar routinely demonstrated 360-degree capability by working together with a second GaN-based AESA antenna that was pointed in a different direction.

As targets flew out of one array’s field of view and into another, the two arrays seamlessly passed information back and forth, tracking the target continuously.  The main array also detected and tracked tactically maneuvering fighter jets and thousands of other aircraft, according to the company.

“Raytheon’s GaN technology is backed by 19 years of research and $300 million in investment, while our competitors are either new to the market or primarily build GaN for commercial applications,” said Ralph Acaba vice president of Integrated Air and Missile Defense at Raytheon’s Integrated Defense Systems business.

Raytheon’s GaN-based AESA radar will work with the Integrated Air and Missile Defense Battle Command System and other open architectures. It maintains compatibility with the current Patriot Engagement Control Station and full interoperability with NATO systems.

A number of current and expected future Patriot Air and Missile Defense System partner nations in Europe and Asia have expressed interest in acquiring GaN-based AESA.   Poland submitted a Letter of Request for GaN-based AESA Patriot on March 31.  Raytheon’s GaN-based AESA technology also meets Germany’s requirements for the German Taktisches Luftverteidigungssystem, or TLVS, tactical air and missile defence system.
